SOLOLIFT2 CWC-3 is a small, compact, ready-to-install automatic lifting station with integrated powerful cutter systems. The lifting station is suitable for pumping wastewater with faeces from private dwellings

Description The ideal pump for lifting sewage and wastewater from the base of the wall-mounted toilet High precision and durability – It has a high-efficiency chopper that does not cause drain blockages – Powerful pumps with strong starting torque for specialized cutting (3, wc-1, CWC) – Components resistant to hot water up to 90°C for 30 minutes (C-3) – Pressure-tight tanks withstand pressures up to 2.5 bar Ease of installation and replacement – It has a non-return valve – It has the possibility of adjusting the emptying in 360 degrees and the horizontal or vertical assembly – It has a flexible discharge connection with a diameter of 6 different pipes for connection – It has a flexible inlet connection and 4 different connection diameters – Application-adjustable starting level (C-3) Ease of maintenance – Small and dry motor unit – Removable motor unit – Easy access to the buoy in a dry and clean manner – A separate drain for the pump tank can be made – Wiring feature using a screwdriver without opening the unit – The possibility of maintaining the unit in place – Keeps the environment clean and healthy (does not need a pit) – Capable of lifting water to 6m vertically and 90m horizontally W C-3 Key Features – 1 WC (base holder) – optional additional sanitary equipment, for example: – washing machine. – shower cabin (higher than pump level). – bidet or urinal. Technical details Maximum height 90 meters Flow rate 4.5 m3/h Liquid temperature 45°C Shaft stainless steel Air temperature up to 45°C Power 0.75 HP Frequency 50/60Hz Current 220V Motor protection grade IPX4D Engine Insulation F Certifications CE, ASNZ4020
