UNILIFT AP50B is a stainless-steel submersible pump designed for pumping wastewater with particles up to 50 mm. It can be installed on an auto coupling, allowing for easy maintenance and other purpose

Description Strength, durability and precision – Single stage vertical submersible pump – Made entirely of stainless steel – The pump has an R2 discharge port Ease and comfort in handling – Equipped with a circular holder to isolate the direct suction hatch from the level of the suction floor to protect it from blockage – Supplied with a carrying handle – Supplied with a main cable of 10 meters – It has a float for automatic start and stop – Ready to install either free standing or automatic coupling system – Easy access for maintenance purposes Super protection – The motor is a class F insulator – Thermal overload protection Technical details Condenser Volume – Run 16 ΜF/400 Volt Cos Phi Power factor 0.98 Density 998.2 kg / m3 Enclosure Class (IEC 34-5) IP69 Gross weight 12.9 lbs / 5.8 kg Maximum distance 11 m Insulation Class (IEC 85)F Power cable length 10 m Level switch float switch Maximum liquid temperature 40℃ Basic frequency 50 Hz Maximum flow 6.67 l/s Maximum installation depth 7 m Particle size maximum 50 mm Motor type 1-phase PSC Net weight 11.6 kg Pressure 20.74 kW Input power 11.2 kW pressure Pump outlet R 2″” Circuit rating 5.37 amps Rated Speed 2790 RPM Voltage 1 x 230V Thermal protection internal “V” impeller type
