UNILIFT APG, single-stage submersible pump designed for pumping domestic wastewater in pressurized systems. Pump is made of wear-resistant materials such as cast iron and stainless steel.

Description The UNILIFT APG pump is a single-stage submersible pump designed for pumping domestic wastewater. The pump is equipped with a grinder r system that grinds destructible solids into small pieces to lead them through pipes with a relatively small diameter. UNILIFT APG pumps are ideal for use in sparsely populated areas, where gravity sewage systems are not available. The solution is ideal in, for example, one-family or two-family houses, residential building services and areas with large terrain-level differences. The pump is available for two types of installation: Submerged installation on auto-coupling systems Submerged installation, free-standing. The pump is made of wear-resistant materials, such as cast iron and stainless steel. These materials ensure reliable operation. The surface of the pump is smooth to prevent dirt and impurities from sticking. Four corrosion-resistant screws secure the motor to the pump housing and allow for easy service of the pump. Technical details: Materials: Pump housing: Cast iron Pump housing: EN 1561 EN-GJL-200 Impeller: Composite Impeller: PPE-PS-GF30 Motor house: Stainless steel Motor house: EN 1.4301 Motor house: AISI 304 Installation: Range of ambient temperature: 0 .. 40 °C Maximum installation depth: 7 m Liquid temperature range: 0 .. 70 °C Electrical data: Power input P1: 1.3 kW Length of power cable: 10 m Power plug: Schuko plug Weight: Net weight: 23.2 kg Gross weight: 24.8 kg
