(VROF35) 9.5mL Cell for Reflection Measurement, 35x15mm, Wall Thickness 2mm, Fused

Description VROF35 Reflection Measurement Quartz Cell is a compact fused quartz cell specifically designed for reflection and optical surface measurements. Featuring a 35 × 15 mm clear aperture and a 2 mm wall thickness, this cell delivers excellent optical clarity and dimensional stability. Its smaller size makes it ideal for high-precision measurements where space efficiency and stability are essential. Key Advantages 35 × 15 mm optical window ensures accurate reflection measurements with minimal distortion. 2 mm wall thickness provides structural stability while maintaining good transmission. Fused fabrication guarantees clean optical surfaces and superior chemical and thermal resistance. Wide UV/VIS spectral range (190–2500 nm) compatible with most spectrophotometers. Perfect for reflection spectroscopy, thin-film testing, and optical surface evaluation. Fused Fabrication Features Can be heated up to 600 °C (1112 °F) for thermal measurement applications. Assembled with quartz powder — micro-gaps may stain over time, so long-term sample storage is not recommended. Excellent resistance to most acids and bases except HF. Not suitable for strong organic solvents such as toluene and acetone, which may damage the fused structure and shorten lifespan. No adhesives used — ensuring a clean optical path with low background noise. Typical Applications Reflection spectroscopy and surface measurements Mirror coating and thin-film analysis Material surface testing and optical metrology Industrial and R&D optical evaluations Technical Specifications Type Reflection Measurement Cell Fabrication Method Fused* Article No. VROF35 Wavelength Range UV/VIS (190 – 2500 nm) Clear Aperture 35 × 15 mm Wall Thickness 2 mm Volume 9.5 mL Material Fused Quartz Thermal Resistance Up to 600 °C (1112 °F) Chemical Resistance Excellent (except HF and strong organics) Disclaimer: Fused quartz cells provide excellent optical quality and chemical resistance. Avoid using hydrofluoric acid (HF) and aggressive organic solvents like toluene and acetone, which can damage the fused structure and shorten the product’s lifespan. For best performance, avoid long-term storage of staining samples and keep the optical surface clean. ImagePart No.Volume (ml)Lightpath (mm)Inner WidthClear WallsFooter (mm)Height (mm)TypesAdd to Cart VNE085-6.511.52-45Reflection CellAdd to cart VNE084-111121245Reflection CellAdd to cart VROF70.2555All715Reflection CellAdd to cart VROM80.2555All815Reflection CellAdd to cart VROF100.888All1020Reflection CellAdd to cart VROF121.31010All1220Reflection CellAdd to cart VROF154.51313All1535Reflection CellAdd to cart VROF15-231111All1535Reflection CellAdd to cart VROF1614.51414All16100Reflection CellAdd to cart VROF29162525All2938Reflection CellAdd to cart VROF30142626All3030Reflection CellAdd to cart VROF359.53131All3515Reflection CellAdd to cart VROF350403333All3550Reflection CellAdd to cart VROF44204040All4420Reflection CellAdd to cart VROF55695050All5538Reflection CellAdd to cart VROF50935050All5550Reflection CellAdd to cart VROF6464--All6438Reflection CellAdd to cart VRM15P0.71515All175Reflection CellAdd to cart VRM150.71515All175Reflection CellAdd to cart
