524 WiFi 6 DR6G17 17dBi Dual Polarized Micro strip Antenna Array 6-7GHz MMCX connector 802.3 11BE/AX/AC/AN, RoHS compliance,

Description This antenna array is designed for 6GHz applications and can be easily built-in portable devices with MHF processes. It has excellent stability and sensitivity to consistently provide high signal reception efficiency.   Electrical Frequency range 5.9~7.3GHz Gain 16.5dBi Polarization Dual, Vertical & Horizontal VSWR,max 2.0:1 3 dB Beam-Width, H-Plane, typ. 30° 3 dB Beam-Width, E-Plane, typ. 30° Input power max 10W Port to port isolation,min 30db Input impedance 50ohm Mechanical Dimensions(HxWxD) 120x105x10mm Weight Connector 2xMMCX /uf.l connectors optional with higher MOQ/ Environmental Storage temperature -40°C ~85°C Storage temperature -40°C ~75°C
